Teledyne Scientific & Imaging Announces 50GHz Track & Hold Amplifiers for Wideband Signal Acquisition and Processing

THOUSAND OAKS, Calif.--(BUSINESS WIRE)--Teledyne Scientific & Imaging, a Teledyne Technologies (NYSE: TDY) company, is expanding its high-speed mixed-signal integrated circuits (IC) product offering with the addition of two Track & Hold Amplifiers with an unprecedented 50 GHz input bandwidth (BW) designed for wideband signal acquisition and processing.

• RTH110 – Track & Hold IC, 50 GHz Input BW, Clock Frequency from 100 MS/s to 1 GS/s
• RTH130 – Track & Hold IC, 50 GHz Input BW, Clock Frequency from 800 MS/s to 14 GS/s

RTH110 – A three-stage Track-and-Hold Amplifier (THA) with an input bandwidth from DC to 50 GHz and a sampling rate from 100 MS/s to 1 GS/s. Total harmonic distortion (THD) is better than -40 dB at 30 GHz and -35 dB at 50 GHz, output signal is 1Vpp differential, and power dissipation ≤1.9 Watts. The RTH110 is ideally suited for broadband test-and-measurement applications to capture waveforms with less than 10 ps rise times.

RTH130 – A two-stage THA with an input bandwidth from DC to 50 GHz and a sampling rate from 800 MS/s to 14 GS/s. THD is better than -35 dB at 50GHz, output signal is 1Vpp differential, and power dissipation ≤1.5 Watts. The RTH130 eliminates the need for local oscillators and mixers in wideband systems making for compact cost-effective RF-to-digital receivers.

Both the RTH110 and RTH130 are available in 4x4mm quad flat no-lead (QFN) package. Die option and evaluation boards also available.
