Mitsubishi Electric to Launch HV100 Dual Type X-Series HVIGBT Modules

For extra powerful and efficient inverter systems in railways, electric power systems and more

TOKYO--(BUSINESS WIRE)--Mitsubishi Electric Corporation (TOKYO: 6503) announced today the coming launch of two new HV100 dual type X-Series HVIGBT modules for higher power, efficiency and reliability in inverter systems for large industrial equipment such as railways and electric power systems. The modules achieve industry-leading^* dual type 600A current ratings with 10kVrms isolation voltage, believed to be unmatched among silicon HVIGBT modules rated at 3.3kV. Sample shipments will start in April 2021.
* According to Mitsubishi Electric research as of December 17, 2020.

Product Features

1) Industry-leading 600A rating for increased capacity

• Current rating of 600A, tops among high-current-density dual types with 10 kVrms isolation voltage and 3.3kV collector-emitter voltage, will help realize high-power, high-efficiency inverter systems for large industrial equipment such as electric railways and DC transmission systems.
• Seventh-generation IGBTs incorporating CSTBT and RFC diodes achieve 8.57A/cm² power density, unsurpassed by other Si-modules (3.3kV/600A version)

For the full text, please visit: www.MitsubishiElectric.com/news/
