Kinetic Technologies Announces New 80-LED Backlight Driver and LCD Bias Power for up to 12” Display Panels

KTZ8868: Delivers big performance in a tiny package by integrating an 8-Channel 40V Backlight with LCD Bias in a protection-rich solution

SAN JOSE, Calif.--()--Power management and video/audio interface leader, Kinetic Technologies, is expanding its display power solutions portfolio with the introduction of KTZ8868. This device is a highly efficient 8-channel LED backlight driver with current sinks, up to a 40V boost voltage, while its 250mA bias output current can drive high resolution and high refresh rated LCDs.

The high switching frequency of the KTZ8868 allows the use of a smaller inductor and capacitor, resulting in a simpler and smaller solution with fewer external components. The input operating range is from 2.7V to 5.5V, accommodating 1-cell lithium-ion batteries or a 5V supply.

Vice President of Marketing at Kinetic Technologies, Jeff Gray, stated, “With design engineers looking for ways to reduce footprint space for their next generation tablets, POS terminals and other mid-sized displays, our leading-edge KTZ8868 driver provides a worry-free solution that integrates what used to be three ICs into one small chip. This device is like no other on the market, powering 80 LEDs with its protection-rich, robust features wrapped in a tiny package."

These built-in protection features of the KTZ8868 include inductor current limit protection, output short circuit protection, output over-voltage protection, LED fault (open or short) protection and thermal shutdown protection.

The very small KTZ8868 is available in a RoHS and green compliant WQFN55-32L (5mm x 5mm, 32 Lead) package that integrates an 8-channel backlight driver and 250mA LCD bias into one chip.

KTZ8868 is available and shipping now. Visit Kinetic Technologies for more information.

Product features include:

Backlight LED Driver

  • Wide input range: 2.7V to 5.5V
  • High efficiency step-up LED driver with 8-Ch current sinks, up to 40V boost voltage
    • Up to 30mA/Ch in backlight mode
    • ±0.7% current matching at 20mA
    • ±2.2% current accuracy at 20mA
  • I2C/PWM dual dimming control scheme
    • High resolution I2C 11-bit linear or exponential dimming
    • Wide range PWM dimming
      • 100Hz to 100kHz frequency range
      • 0.2% to 100% duty cycle at 20kHz
  • Programmable current sink turn on/off ramp time/shape and transition ramp up/down time
  • 1.0MHz typical boost switching frequency
  • Programmable input PWM hysteresis to minimize jitter at low PWM duty cycle
  • Programmable OVP and current limitation
  • LED open/short protection

LCD Panel Bias

  • Wide input range: 2.7V to 5.5V
  • Programmable dual output Bias regulator using a single inductor
  • Programmable ramp time for OUTP and OUTN
  • Charge pump PFM mode at light load
  • LCD Bias efficiency: up to 85%
  • Wide dual output voltage range ±4.0V to ±6.3V (50mV/step) & output current up to 250mA at VIN ≥ 2.9V
  • Active output discharge function
  • Current limitation and short protection

Other Features

  • System level input UVLO
  • Thermal shutdown protection
  • Low shutdown current <1μA
  • Flexible I2C interface
  • Pb-free package: WQFN55-32L (5mm x 5mm, 32 Lead)
  • RoHS and green compliant
  • -40°C to +85°C temperature range
